Octopack standard specification

  • To suit Hooklift/Cablelift lifting equipment
  • 5mm base
  • 5mm headboard
  • 5mm sides and 3mm roof
  • Single universal door with turnbuckle, ratchet or lever locking gear
  • Secondary locking pin
  • Grease nipple on hinges/rollers
  • Weld numbers
  • Fully welded side seams
  • 2 free running rollers
  • Striker plate and safety deflector plate
  • Single tapered sides
  • Lower internal deflector plate
  • “C” plate to suit CHEM standard
  • 2 tubes, 4 pins and PVC cover
  • 2 vent holes in headboard

Optional extras

  • Transpak door
  • Cattle ramp fastener locking
  • Overcam locking
  • Full web plate
  • Male/female door guides
  • Signboards
  • 2 colours
  • Vinyls/stencil
  • Marker boards
  • Protective edge for marker boards
  • Poly covered rollers with bearings
  • Sealed special application guillotine door hydraulically operated
  • Double taper
  • Overcam with S U Safety Locking
  • Swaged sides
  • Infills base
  • Extra x members
  • Extra uprights
  • Extended striker plate
  • Extra rollers
  • Removable rollers
  • Aperture for screw compactors

We can manufacture larger sizes if required, including compaction containers for articulated vehicles.

PDF datasheet

Download the Interface Dimensions datasheet

Popular Sizes (cuyd) Length (mm) Width (mm) Height (mm) Weight
30 6145 2550 2260 3174kg
35 6145 2550 2580 3369kg
40 6145 2550 2863 3567kg
*Nominal full external dimensions
